Reagent related errors: XN-10/20

Reagent related errors: XN-10/20
Error Code	CELLPACK RELATED errors 131020: CELLPACK DCL aspiration error 132019: FCM sheath aspiration error 132020: RBC sheath fluid aspiration error. Flourocell related errors: 135300: Fluorocell WNR aspiration error 131100: Fluorocell WDF aspiration error 135330: Fluorocell WPC aspiration error 135310: Fluorocell RET aspiration error 135320: Fluorocell PLT aspiration error Reagent replacement Out of CELLPACK DCL Out of SULFOLYSER Out of Lysercell WNR Out of Lysercell WDF Out of Lysercell WPC Out of CELLPACK DFL
Symptom	QC results are abnormal. Patient results are abnormal. Fluid leakage from side of analyser or on top of sample tubes. Error message not executable.
Possible Causes	CELLPACK Related errors The tubing connected to the reagent is clogged. There is a foreign object pressing on the connected tubing. DCL tubing is not connected properly. Flourocell related errors Air bubbles have formed in the tubing connected to the reagent container. Reagent container is faulty. Dye cover is opened. Reagent replacement The reagent has run out.
Refining Problem Area	Which reagent is the problem occurring in? Take note of the related reagent lot number. When was the related reagent last changed? What parameters are being affected? How often is the error occurring? Are there any other errors that are occurring simultaneously? How long has the error been occurring?
Action	Remove the object or foreign body that is pressing on the tube. Registering new reagent 1. Display the [reagent replacement] box. 2. Remove the cap from the new reagent container. 3. Input the reagent barcode using the barcode scanner. 4. Remove the camp from the old reagent container. 5.  Pull the dispensing set straight up. 6. Insert the dispensing set straight into the new reagent container. 7. Close the cap. 8. Click [Execute].  A guide for how long each reagent replenishment will take are shown below.
